2.2KW 6kg/H Lab Twin Screw Extruder For High Molecular Material

2.2KW 6kg/H Lab Twin Screw Extruder For High Molecular Material

  • 2.2KW 6kg/H Lab Twin Screw Extruder For High Molecular Material
2.2KW 6kg/H Lab Twin Screw Extruder For High Molecular Material
Product Details:
Place of Origin: China
Brand Name: RUIMING
Model Number: SJZS
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Delivery Time: 30-90DAYS
Contact Now
Detailed Product Description
Material: Stainless Steel Screw Design: Double Screw
Color: Customizable Brand: RUIMING
Plastic Processed: Plastic Polymer Application:: Laboratory, Research And Development
Automatic Grade: Automatic,Auto,semi-automatic Certification: Patent
High Light:

6kg/H Lab Twin Screw Extruder


2.2KW Lab Twin Screw Extruder


High Molecular Material Lab Extruder

Lab Micro Twin Screw Extruder for high molecular material


Specification of  micro twin crew extruder


Key Technical Parameters SJZS-7A SJZS-10A SJZS-10B SJZS-10Z
Extruder Screw diameter (mm) 7/25 10/30 10/30 10/30
Screw thread length (mm) 190 190 250 190
The screw rotation speed (rpm) 70 51 51 51
Barrel form Can open Can open Can open Can open
Extruder Main motor power( kw) 0.55 0.75 0.75 0.75
Circulating extrusion dosage (g/per time) 5-10(manual control) 15-18(auto control) 15-18(auto control) without
Direct extrusion dosage (max kg/h) 0.45 1.5 1.5 1.5
Heating temperature (max ℃) 450 450 450 450
Feed 1 power (W) without 25(optional) 25 25
Feed 2 power ( W) without without 25 without
Power of vacuum exhaust and dehumidification device (W) without without 180(optional) without
Nitrogen protection have have have have
Extruder size (mm) 800X350X580 800X350X580 850X350X580 800X350X580


Extruder Key Technical Parameters SJZS-20 SJZS-20A
Extruder Screw diameter (mm) 20/40 20/53
Screw thread length (mm) 390 480
The screw rotation speed (rpm) 0-50 51
Barrel form Do not open Do not open
Main motor power( kw) 1.5 2.2
Circulating extrusion dosage (g/per time) without without
Direct extrusion dosage (max kg/h) 6 6
Heating power (kw) 4.5 5
Feed 1 power (W) 25(optional) 25
Feed 2 power (W) without 25
Power of vacuum exhaust and dehumidification device (W) 250(optional) 250(optional)
Nitrogen protection have have
Extruder Size (mm) 1020x450x600 1120x450x600


Advantages of micro twin screw extruder


SJZS series mini twin screw extruder is a new generation of experimental equipment combining the advantages of internal mixer.

It has the following characteristics:

Ο Less raw materials, precision ingredients, operating temperature: from room temperature to 450°, can work placed on the experimental table or fume cabinet.

Ο Easy to operate, good plasticizing dispersion performance, can be timed cycle extrusion or continuous extrusion. The process can be inert gas protection and vacuum exhaust. The barrel can be opened and the screw can be disassembled for easy cleaning.

Ο Change different head and the corresponding auxiliary machine which produced by our company, in the continuous extrusion state, it can produce products shaped as plastic pipe blowing bottle, film, sheet, profile, spinning, cutting, coating and other plastic products.

Ο It can be used with the micro-injection machine produced by our company. The material can be directly squeezed into the injection sleeve of the injection machine from the extrusion outlet, and directly facilitate the injection molding of the required spline.

Ο Suitable for almost all thermoplastic polymers PEEK, PLA, PA, PC, etc., or add magnetic particles, porcelain powder, graphene, PTFE powder, metal powder, glass fiber (powder can reach nanoscale)

2.2KW 6kg/H Lab Twin Screw Extruder For High Molecular Material 02.2KW 6kg/H Lab Twin Screw Extruder For High Molecular Material 1
