50rpm Small Double Screw Extruder Machine 390mm Screw Thread Length

50rpm Small Double Screw Extruder Machine 390mm Screw Thread Length

  • 50rpm Small Double Screw Extruder Machine 390mm Screw Thread Length
50rpm Small Double Screw Extruder Machine 390mm Screw Thread Length
Product Details:
Place of Origin: China
Brand Name: RUIMING
Certification: patent
Model Number: SJZS
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: carton box and wooden box
Delivery Time: 20-90 days after order confirmed
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 sets per month
Contact Now
Detailed Product Description
Screw Diameter (mm): 10/30 The Screw Rotation Speed (rpm): 51
Direct Extrusion Dosage (max Kg/h): 1.5 Heating Temperature (max ℃): 450
Nitrogen Protection: Have Size (mm): 800X350X580
High Light:

Small Double Screw Extruder Machine

,

50rpm Double Screw Extruder Machine

,

390mm twin screw compounding extruder

Twin Screw Extruder With PLC Control Communication System



Introduction of Twin Screw Extruder

Twin screw extruder adopts PLC control communication system, equipped with integrated feeder control and easy to remove product contact parts. Compact single shell structure design, cover a small area, is the ideal choice for fume hood applications. Screw elements and cartridges are designed to scale geometrically through all extruders for easy process magnification.



Parameters of Twin Screw Extruder

Key Technical Parameters SJZS-7A SJZS-10A SJZS-10B SJZS-10Z
Screw diameter (mm) 7/25 10/30 10/30 10/30
Screw thread length (mm) 190 190 250 190
The screw rotation speed (rpm) 70 51 51 51
Barrel form Can open Can open Can open Can open
Main motor power( kw) 0.55 0.75 0.75 0.75
Circulating extrusion dosage (g/per time) 5-10(manual control) 15-18(auto control) 15-18(auto control) without
Direct extrusion dosage (max kg/h) 0.45 1.5 1.5 1.5
Heating temperature (max ℃) 450 450 450 450
Feed 1 power (W) without 25(optional) 25 25
Feed 2 power ( W) without without 25 without
Power of vacuum exhaust and dehumidification device (W) without without 180(optional) without
Nitrogen protection have have have have
size (mm) 800X350X580 800X350X580 850X350X580 800X350X580




Key Technical Parameters SJZS-20 SJZS-20A
Screw diameter (mm) 20/40 20/53
Screw thread length (mm) 390 480
The screw rotation speed (rpm) 0-50 51
Barrel form Do not open Do not open
Main motor power( kw) 1.5 2.2
Circulating extrusion dosage (g/per time) without without
Direct extrusion dosage (max kg/h) 6 6
Heating power (kw) 4.5 5
Feed 1 power (W) 25(optional) 25
Feed 2 power (W) without 25
Power of vacuum exhaust and dehumidification device (W) 250(optional) 250(optional)
Nitrogen protection have have
Size (mm) 1020x450x600 1120x450x600
