SZS-30 80 Ton Automatic Injection Molding Machine For University Lab

SZS-30 80 Ton Automatic Injection Molding Machine For University Lab

  • SZS-30 80 Ton Automatic Injection Molding Machine For University Lab
SZS-30 80 Ton Automatic Injection Molding Machine For University Lab
Product Details:
Place of Origin: China
Brand Name: RUIMING
Certification: patent
Model Number: SZS
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: carton box and wooden box
Delivery Time: 20-90 days after order confirmed
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 sets per month
Contact Now
Detailed Product Description
Injection Pressure (MAX Mpa): 45/120/160 Mould Clamping Force (MAX T): 12/40/80
Injection Capacity (MAX G): 15/20/30 Template Temperature Control Power (W): 400/800/1000
Size ( Mm): 700x320x450 Weight ( Kg): 90/120/135
High Light:

SZS-30 Automatic Injection Molding Machine

,

University Lab mini molding machine

,

80T mini plastic injection molding machine

Automatic Injection Molding Machine Plunger Type Structure



Wuhan Ruiming Experimental Instrument Manufacturing Co., Ltd. successfully developed and issued laboratory mini-twin screw extruder and laboratory mini-injection molding machine series products which with advanced technology both in domestic and aboard. The series of mico extruder and micro injection machine have achieved and surpassed the technology level of similar foreign products such as HAAKE MiniLab, MiniJet and DSM Xplore in many aspects, but with high cost performance, they are ideal imported alternative products. Especially suitable for laboratory research of university and development department of enterprise, in addition to domestic universities, research units, company research and development department, our products also exported to the United States, Canada, Russia, Saudi Arabia, Azerbaijan and so on.



Key Technical Parameters of Automatic Injection Molding Machine





Key technical parameters SZS-15 SZS-20 SZS-30
Injection pressure (MAX Mpa) 45 120 160
mould clamping force (MAX T) 12 40 80
injection capacity (MAX g) 15 20 30
Temperature control area 2 2 2
Temperature control power of injection tube (W) 180 250 280
Template temperature control power (W) 400 800 1000
Voltage (V) 200-240 200-240 200-240
Rated current ( A) 3.5 5.0 7.0
Heating temperature (MAX ℃) 320 450 450
Size ( mm) 700x320x450 800x320x450 800x360x450
Weight ( kg) 90 120 135
