240V 80T Small Plastic Injection Molding Machine Plunger Type

240V 80T Small Plastic Injection Molding Machine Plunger Type

  • 240V 80T Small Plastic Injection Molding Machine Plunger Type
240V 80T Small Plastic Injection Molding Machine Plunger Type
Product Details:
Place of Origin: China
Brand Name: RUIMING
Certification: patent
Model Number: SZS
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: carton box and wooden box
Delivery Time: 20-90 days after order confirmed
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 sets per month
Contact Now
Detailed Product Description
Template Temperature Control Power (W): 400/800/1000 Voltage (V): 200-240
Rated Current ( A): 3.5/5.0/7.0 Heating Temperature (MAX ℃): 320/450
Size ( Mm): 800x360x450 Weight ( Kg): 90/120/135
High Light:

80T Small Plastic Injection Molding Machine

,

240V small plastic injection molding machine

,

Plunger Type mini plastic moulding machine

Automatic Injection Molding Machine Plunger Type Structure



Wuhan Ruiming Plastic Machinery Co., Ltd. is located in wuhan, the historical and cultural city, the capital of Hubei province, which was established in 2001. The company is a professional manufacturer of polymer experimental equipment, specializing in the production of miniature double-cone twin-screw screw extruder, experimental micro-extruder, micro-injection machine, micro-high tensile ratio spinning machine, micro-extrusion unit, micro-granulator unit and experimental plastic blowing machine series products and so on. The company also successfully developed and issued the leading level of laboratory mini twin screw extruder and laboratory mini injection molding machine series products. Main performance indicators of the series of mini extruder and mini injection machine have achieved and surpassed the level of similar foreign products such as HAAKE MiniLab and DSM Xplore in many aspects, but have high cost performance. Especially suitable for the laboratory research needs of universities and enterprise R&D departments



Key Technical Parameters of Automatic Injection Molding Machine





Key technical parameters SZS-15 SZS-20 SZS-30
Injection pressure (MAX Mpa) 45 120 160
mould clamping force (MAX T) 12 40 80
injection capacity (MAX g) 15 20 30
Temperature control area 2 2 2
Temperature control power of injection tube (W) 180 250 280
Template temperature control power (W) 400 800 1000
Voltage (V) 200-240 200-240 200-240
Rated current ( A) 3.5 5.0 7.0
Heating temperature (MAX ℃) 320 450 450
Size ( mm) 700x320x450 800x320x450 800x360x450
Weight ( kg) 90 120 135
