Fully Automatic 50rpm Mini Lab Extruder With PLC Control

Name: Fully Automatic 50rpm Mini Lab Extruder With PLC Control
Brand: Wuhan Ruiming Experimental Instrument
SKU: SJZS
Availability: InStock

Brand Name:	RUIMING
Model Number:	SJZS
MOQ:	1pcs
Price:	Negotiable
Delivery Time:	30-90DAYS
Payment Terms:	L/C, D/A, D/P, T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

patent

Screw Diameter (mm):

20/40

Screw Thread Length (mm):

390

The Screw Rotation Speed (rpm):

0-50

Barrel Form:

Do Not Open

Main Motor Power( Kw):

1.5

Circulating Extrusion Dosage (g/per Time):

Without

Packaging Details:

carton box and wooden box

Supply Ability:

200 sets per month

Highlight:

50rpm Mini Lab Extruder

Fully Automatic Mini Lab Extruder

Lab Extruder With PLC Control

Product Description

Mini Lab Extruder With PLC Control Full Automatic

Parameters of mini lab extruder

Key Technical Parameters	SJZS-20	SJZS-20A
Screw diameter (mm)	20/40	20/53
Screw thread length (mm)	390	480
The screw rotation speed (rpm)	0-50	51
Barrel form	Do not open	Do not open
Main motor power( kw)	1.5	2.2
Circulating extrusion dosage (g/per time)	without	without
Direct extrusion dosage (max kg/h)	6	6
Heating power (kw)	4.5	5
Feed 1 power (W)	25(optional)	25
Feed 2 power (W)	without	25
Power of vacuum exhaust and dehumidification device (W)	250(optional)	250(optional)
Nitrogen protection	have	have
Size (mm)	1020x450x600	1120x450x600

The features of the mini lab extruder

1. low consumption,

2. high quality screw and barrel (38CrMoAlA, nitriding), long service time.

3. with PLC control, full automatic, easy operation.

4. wide use, with different molds, different use.
